F6 Strip IP
F6 Strip IP is an outdoor-ready, uniquely shaped 6.9 mm pixel pitch video panel that can be used to line set-pieces and configure designs that compliment other video wall panels in the F-series (F2, F3, F4IP, F5IP). Since it takes HDMI/DVI/SDI directly into the VIP Drive 83R video processor and features the same mapping software (Smart-LCT) as other F-series video panels, there is no need to setup a separate, dedicated video server when using F6 Strip IP with other video panels in the range. Its elongated, die-cast housing makes this product among the lightest and slimmest in its class without compromising its strength. F6 Strip IP runs on the Novastar control platform, and includes 2 diffusion filters (square soft white, square black stealth) for further versatility.
Lo destacado
6.9 mm pitch high resolution outdoor video strip works with the VIP Drive 83R, using the Novastar control protocol
High quality black body LEDs accurately reproduce video at 15 bit grayscale, operating on a customized receiver card from Novastar
5000:1 contrast ratio greatly improves the video performance
High performance digital LED drivers deliver 5940Hz refresh rate and a clear, vibrant image
Intelligent, modular LED modules with dedicated memory store factory calibration, ensuring optimal image quality, color uniformity, and simplifies maintenance by making service fast and easy
1,000 x 34.5 x 68.2 mm, 4.85 lb (2.2 kg) aluminum extrusion and die-cast housing makes this product among the lightest and slimmest in its class without compromising strength
Specialized design supports hardware for end-to-end linking/hanging and 180° angling capabilities
Pixel pitch is maintained for 0° end-to-end linking, as well as mounting next to each other, even when the filters are installed
Design features to prevent damage to the LEDs when handling: multiple clear, front standoffs keep the LEDs from getting damaged from impacts, and includes specialized LED board design to improve impact resistance up to 3x that of other products, and resilient led mask design to optimize image viewing angle and uniformity without exposing the LEDs to front or side impacts
Flexible mounting options include 2pcs adjustable 13mm mounting brackets on either side, as well as 1pc M12 threaded insert in the center
Optimized heat dissipation (convection cooled) ensures an even color across the F6 Strip IP
Compact power supply, designed solely for this product, increases the stability of the system
2-in-1 power/data cables offer quick connection, and are IP-rated for indoor and outdoor environments
PowerKON and etherKON break in, break outs, and 2-in-1 linking cables available
2 Diffusion filters included with the F6 Strip IP (square soft white and square black stealth)
VIP Drive 83R Nova required for operation
Quick Lock 2-in-1 power/data cables offer quick connection, are IP-rated for indoor and outdoor environments, and are available in direct linking, break in, and break out cables
Especificaciones
Óptica
- Light Source: 720 LEDs (tri-color RGB) SMD 1921, 50,000 hours life expectancy
- Color Wavelength: red (615 to 630 nm), green (515 to 535 nm), blue (460 to 475 nm)
- Viewing Angle (H/V): 160°/155°
- Calibrated Illuminance: 5500 NITS
- Maximum Illuminance: 5500 NITS
- Contrast Ratio: 5,000: 1
- Pixels: 144 x 5
- Pixel Pitch: 6.9 mm
- Minimum Viewing Distance: 10 ft (3 m)
- Grayscale: 15 bit
- Pixel Density: 20,736/m2
- Display Refresh Rate: 5,940 Hz
Construcción / Características físicas
- Dimensions: 39.37 x 1.36 x 2.69 x in (1,000 x 34.5 x 68.2 mm)
- Weight: 4.85 lb (2.2 kg)
- Threaded Bolt: M12
- Exterior Color: Black
- Housing Material: Aluminum extrusion and Aluminum die-cast
- Maximum vertical hang: 4 strips
- Transparency: 0%
Conexiones
- Power Connection: Edison (Local) plug to Seetronic TRUE1
- Power Input: Seetronic TRUE1
- Power Output: Seetronic TRUE1
- Data Connectors: Seetronic etherCON SE8FC-L
- Cable Length (power): 5 ft (1.5 m)
Control
- Control Protocol: Novastar
- Maximum Strips/VIP Drive 83R (0° or 90° orientation): 70/port, 560/Drive (8 ports)
- Maximum Strips Wide/VIP Drive 83R (horizontal orientation): 26
- Maximum Strips Tall/VIP Drive 83R (vertical orientation): 7
Eléctrico
- Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
- Power Linking: 50 units @ 120 V; 55 units @ 208 V; 60 units @ 230 V
- Power and Current: 32 W, .265 A @ 120 V, 60 Hz
- Power and Current: 52 W, .248 A @ 208 V, 60 Hz
- Power and Current: 53 W, .229 A @ 230 V, 50 Hz
- Power and Current (resting): 3 W, .049 A @ 120 V, 60 Hz
- Power and Current (resting): 2 W, .038 A @ 208 V, 60 Hz
- Power and Current (resting): 2 W, .034 A @ 230 V, 50 Hz
Certificaciones / Calificaciones
- Power and Current (resting): 2 W, .034 A @ 230 V, 50 Hz
- IP Rating: IP65, temporary outdoors
- Thermal Dissipation @120V: 109 BTU per hour
- Thermal Dissipation @ 208V: 177 BTU per hour
- Thermal Dissipation @ 230V: 180 per hour
- Operating Temperature: -4 °F to 122 °F (-20 °C to 50 °C)
Accesorios incluidos
- Warranty Card
- QRG
- 1pc square milky filter (for diffused output)
- 1pc black stealth filter (for high contrast applications)
Accesorios necesarios
- Required Software: Nova Smart LCT
- Controller (required): VIP Drive 83R Nova
- Compatible Mounting Options: M12 clamp, ½” clamp, ¼-turn clamp
- QUICKLOCKIPINCABLE- QUICK LOCK IP INPUT CABLE for etherKON and powerKON
Accesorios opcionales
- ArKaos Media Master Express™ + KN software
- Clamps
- Seetronic TRUE1 cables
- Neutrik etherCON cables
- Fast clamp
- QUICKLOCKIPEXT16IN: 2 IN 1 VIDEO EXTENSION CABLE-16INCH
- QUICKLOCKIPEXT 5FT: 2 IN 1 VIDEO EXTENSION CABLE-5FT
- QUICKLOCKIPEXT 15FT: 2 IN 1 VIDEO EXTENSION CABLE-15FT
- QUICKLOCKIPEXT 25FT: 2 IN 1 VIDEO EXTENSION CABLE-25FT
- QUICKLOCKIPEXT 50FT: 2 IN 1 VIDEO EXTENSION CABLE-50FT
- QUICKLOCKIPEXT OUTCABLE: 2 IN 1 VIDEO OUTPUT CABLE
- QUICKLOCKIPEXT INCABLE: 2 in 1 video input cable
Descargas
F6 Strip IP - Quick Reference Guide
F6 Strip IP – CAD/DWG
Descargar Archivo de Personalidades ChamSys
